Custom Modules

As versatile as your applications

Individual equipment options
Future-proofing thanks to interchangeable modules
Simple and flexible installation

Custom Modules are the central components of video, audio and network connections. Their construction offers you simple and flexible installation. With the easily interchangeable modules, you can create units to meet the individual data, video and audio connection requirements of your customers quickly and simply, no matter if an office environment, but also in rack and electrical installations.

BACHMANN also offers this flexibility for 19" panel installations. The standard Custom Modules facilitate optimal configuration for every media and network connection requirement. Here, socket/socket or screw-terminal connections also provide great simplicity of installation.

When it comes to electrical installations, BACHMANN Custom Modules are another outstanding addition. The small number of components makes the Custom Modules compatible with the current switch ranges of reputable manufacturers. Simple mounting and removal mean that all installations can be quickly adapted to changed requirements or brought up to the current state of the art.

Custom Modules

Keystones socket/socket

CAT6A coupling, socket/socket

940.083

Front side: RJ45 (keystone fixing)
Back side: RJ45 (keystone fixing)
Shielded

CAT6 Class 90° coupling socket/socket

918.032

90° lateral outlet, only compatible with power strips with lateral 90° outlet
Type: METZ CONNECT (E-DAT) I Front side: RJ45 (keystone fixing)
Back side: RJ45 (E-DAT mounting) | Shielded

CAT6 Class E_A coupling socket/socket

940.044

For 10 Gbit Ethernet
Type: METZ CONNECT E-DAT
Front side: RJ45 (keystone fixing)
Back side: RJ45 (E-DAT mounting)
Shielded

CAT6 coupling, socket/socket

940.112

Front side: RJ45 (keystone fixing)
Back side: RJ45 (keystone fixing)
Unshielded

ISDN RJ12 socket/socket

940.085

Front side: RJ12 (keystone fixing)
Back side: RJ12 (keystone fixing)
Unshielded

Keystones socket/supply cable

CAT6a 10GB patch cable plug/socket 3.0 m

918.033

Front side: Socket RJ45 CAT6a TKM 10GB
Cable, black, with RJ45 plug
Shielded

CAT6a 10GB patch cable plug/socket 5.0 m

918.034

Front side: Socket RJ45 CAT6a TKM 10GB
Cable, black, with RJ45 plug
Shielded

CAT6a 10GB socket TKM

918.035

CAT6a connector socket TKM 10GB
For self-connection
Without cable (designed for tool-free connection of data cable)
Shielded

Keystones for media technology

1 x HDMI 2.0

918.041

1 x miniature jack 3.5 mm

917.157

Front side: 3.5 mm stereo miniature jack socket
Back side: 3.5 mm stereo miniature jack socket with approx. 0.2 m cable
Requires approx. 65 mm mounting depth
Black

1 x Mini DisplayPort

917.214

Front side: Mini DisplayPort socket
Back side: DisplayPort plug with approx. 0.5 m cable
Requires approx. 85 mm mounting depth
Black

USB 3.0 keystones

Requires approx. 85 mm mounting depth
Black

917.120

USB 3.0 A/A (straight-through)
Front side: USB-A socket
Back side: USB-A socket

917.401

USB 3.0 B/A
Front side: USB-B socket
Back side: USB-A socket

917.400

USB 3.0 A/B USB
Front side: USB-A socket
Back side: USB-B socket

USB 3.1 Type C keystone

Black
Requires approx. 50 mm mounting depth

917.1212

USB 3.1 Type C PD 60 W
Front side: USB C socket
Back side: USB C plug with approx. 0.5 m cable

917.121

USB 3.1 type C PD 36 W
Front side: USB-C socket
Back side: USB-C plug with approx. 0.5 m cable

Keystones OWG

Keystone fixing

918.045

TOSLINK optical-fibre audio coupling

918.071

OWG-LC duplex coupling

918.073

OWG-ST duplex coupling

918.072

OWG-SC coupling

Custom Module VGA, jack, HDMI

917.226

Custom Module equipped with: Breakout cables, approx. 0.2 m, socket-socket for VGA
Audio (3.5 mm stereo jack)
HDMI (keystone clip)
Requires approx. 110 mm mounting depth

Custom module 1 x VGA + miniature jack

917.058

90° lateral outlet, only compatible with power strips with lateral 90° outlet I Front side: VGA socket and 3.5 mm stereo miniature jack | Back side: VGA socket and 3.5 mm stereo miniature jack with approx. 0.2 m cable | Requires approx. 40 mm mounting depth | Black

917.045

Front side: VGA socket and 3.5 mm stereo miniature jack
Back side: VGA socket and 3.5 mm stereo miniature jack with approx. 0.1 m cable
Requires approx. 70 mm mounting depth
Black

917.150

Front side: VGA socket and 3.5 mm stereo miniature jack
Back side: VGA socket and 3.5 mm stereo miniature jack, each with approx. 0.2 m cable
Requires approx. 50 mm mounting depth
Black

Custom Module 1 x VGA + miniature jack and button

917.134

Front side: VGA socket and 3.5 mm stereo miniature jack + button, blue illuminated
Back side: VGA socket and 3.5 mm stereo miniature jack with approx. 0.1 m cable + RJ12 socket for button
Requires approx. 70 mm mounting depth
Black

Custom Module 1 x VGA

917.011

Front side: VGA socket
Back side: VGA socket
Requires approx. 70 mm mounting depth
Black

Custom Module 1 x DVI-I

917.078

Front side: DVI-I socket
Back side: DVI-I socket with approx. 0.2 m cable
Requires approx. 75 mm mounting depth
Black

Custom Module 1 x HDMI

917.143

Black
Front side: HDMI socket
Back side: Screw terminal 2 x 9-pole (HDMI)
Requires approx. 40 mm mounting depth

917.146

90° lateral outlet, only compatible with power strips with lateral 90° outlet I Black I Front side: HDMI socket I Back side: HDMI socket | Requires approx. 35 mm mounting depth

Custom module 1 x HDMI + miniature jack

917.189

90° lateral outlet, only compatible with power strips with lateral 90° outlet I Front side: HDMI socket and 3.5 mm stereo miniature jack
Back side: HDMI socket and 3.5 mm stereo miniature jack with approx. 0.2 m cable
Requires approx. 65 mm mounting depth
Black

Custom Module 1 x DisplayPort

917.145

Front side: DisplayPort socket
Back side: DisplayPort socket without cable
Requires approx. 70 mm mounting depth
Black

Custom Module 1 x Cinch video + 2 x Cinch audio stereo

917.026

Black
Front side: Cinch video (yellow) + 2 x cinch audio stereo (red + white) socket
Back side: Cinch video + 2 x cinch audio stereo socket without cable

Custom Module 1 x Cinch video RGB

917.090

Front side: Cinch video RGB socket (red/green/blue)
Back side: Cinch video RGB socket (red/green/blue)
Requires approx. 65 mm mounting depth
Black

Custom Module 1 x SAT/TV/radio

917.030

Front side: F-plug connector (sat) and 2 x COAX (TV + radio)
Back side: F-plug connector (sat) and 2 x COAX (TV + radio)
Requires approx. 50 mm mounting depth
Black

Custom Module 1 x TV/radio

917.117

Front side: 2 x COAX (TV + radio)
Back side: 2 x COAX (TV + radio)
Requires approx. 50 mm mounting depth
Black

Custom Module 1 x Cinch audio stereo

Front side: Cinch audio stereo socket (red + white)

917.022

Black
Back side: Cinch audio stereo (red + white) socket without cable
Requires approx. 55 mm mounting depth

Custom Module 1 x 3.5 mm miniature jack

Front side: 3.5 mm audio stereo miniature jack socket

917.023

Black
Back side: Cinch audio stereo socket (red + white)
Requires approx. 65 mm mounting depth

917.091

Black
Back side: 3-pole screw terminal (audio stereo)
Requires approx. 35 mm mounting depth

Custom Module 1 x XLR 3-pole microphone

917.024

Front side: XLR 3-pole microphone socket
Back side: XLR 3-pole plug with approx. 0.1 m cable
Requires approx. 65 mm mounting depth
Black

Custom Module 1 x XLR socket

Front side: XLR socket
Back side: Screw terminal
Requires approx. 40 mm mounting depth

917.096

3-pole
Black

917.101

5-pole
Black

Custom Module for Rextron HDBaseT

Cable lengths 1 m

903.205

HDMI digital
Custom Module HDMI, button
1 x HDMI socket/plug
1 x blue illuminated button with RJ11 plug

903.204

VGA analogue
Custom Module VGA, miniature jack and button
1 x VGA 15-pole socket/plug
1 x 3.5 mm miniature jack socket/plug
1 x blue illuminated button with RJ11 plug

903.206
