DESK 2

DESK 2

DESK 2

Design meets technology
Product ImageProduct ImageProduct Image
  • For modern living and work environment
  • User-focused 35° orientation
  • Covered cable routing to the edge
  • Custom Versions

DESK 2 is a power strip that can be populated with various communication modules and is perfect for all kinds of uses. DESK 2 is a power strip that can be equipped with various communication modules. It has been designed for flexible use in the office, meeting rooms, home offices or desk-sharing environments. But DESK 2 is great in living spaces, too.

The power strip is made from aluminium and is available in various colours. The connections are screwed onto the standardised module windows and can be easily converted.

Technical data

Dimensions

from 155x85x100 mm

Material

Profile: aluminium

Socket: plastic

Surface-mounted units

Tabletop thickness: 10–40 mm

Icon_Colour_Inox
Inox
Icon_Colour_Schwarz
Black
Icon_Colour_Weiss
White
Socket outlet with earthing contact
UTE socket
Swiss socket (10 A)
UK socket (3,15 A)
Italy / socket outlet with earthing contact
USB Charger
Custom Module
Shutter

DESK 2

DESK 2 power strips – white, similar to RAL9010

  • Profile: Aluminium, painted white, similar to RAL9010
  • Socket: Black plastic
  • Tabletop thickness: 10 – 40 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

Number of other sockets
Angle of twisted central insert
USB charger
Custom Module
Dimensions

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.214
Number of other sockets 4
Angle of twisted central insert 45°
USB charger
Custom Module
Dimensions 336 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.947
Number of other sockets 2
Angle of twisted central insert 45°
USB charger A&C 22W
Custom Module 1
Dimensions 294 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.948
Number of other sockets 2
Angle of twisted central insert 45°
USB charger C 30W
Custom Module 1
Dimensions 294 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.949
Number of other sockets 2
Angle of twisted central insert 45°
USB charger C 60W
Custom Module 1
Dimensions 336 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.231
Number of other sockets 2
Angle of twisted central insert 45°
USB charger A/A 15W
Custom Module 1
Dimensions 294 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.206
Number of other sockets 2
Angle of twisted central insert 45°
USB charger
Custom Module 1
Dimensions 251 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.944
Number of other sockets 2
Angle of twisted central insert 45°
USB charger A&C 22W
Custom Module
Dimensions 251 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.945
Number of other sockets 2
Angle of twisted central insert 45°
USB charger C 30W
Custom Module
Dimensions 251 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.946
Number of other sockets 2
Angle of twisted central insert 45°
USB charger C 60W
Custom Module
Dimensions 294 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.213
Number of other sockets 2
Angle of twisted central insert 45°
USB charger
Custom Module
Dimensions 209 x 86 x 88 mm
Show more

DESK 2 power strips – stainless steel

  • Profile: Aluminium, painted in stainless steel
  • Socket: Black plastic
  • Tabletop thickness: 10 – 40 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

Number of other sockets
Angle of twisted central insert
USB charger
Custom Module
Dimensions

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.917
Number of other sockets 2
Angle of twisted central insert 45°
USB charger A&C 22W
Custom Module 1
Dimensions 294 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.918
Number of other sockets 2
Angle of twisted central insert 45°
USB charger C 30W
Custom Module 1
Dimensions 294 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.919
Number of other sockets 2
Angle of twisted central insert 45°
USB charger C 60W
Custom Module 1
Dimensions 336 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.431
Number of other sockets 2
Angle of twisted central insert 45°
USB charger A/A 15W
Custom Module 1
Dimensions 294 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.913
Number of other sockets 2
Angle of twisted central insert 45°
USB charger A&C 22W
Custom Module
Dimensions 251 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.914
Number of other sockets 2
Angle of twisted central insert 45°
USB charger C 30W
Custom Module
Dimensions 251 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.915
Number of other sockets 2
Angle of twisted central insert 45°
USB charger C 60W
Custom Module
Dimensions 294 x 86 x 88 mm
Show more

DESK 2 power strips – black, similar to RAL9005

  • Profile: Aluminium, painted black, similar to RAL9005
  • Socket: Black plastic
  • Tabletop thickness: 10 – 40 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

Number of other sockets
Angle of twisted central insert
USB charger
Custom Module
Dimensions

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.977
Number of other sockets 2
Angle of twisted central insert 45°
USB charger A&C 22W
Custom Module 1
Dimensions 294 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.978
Number of other sockets 2
Angle of twisted central insert 45°
USB charger C 30W
Custom Module 1
Dimensions 294 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.979
Number of other sockets 2
Angle of twisted central insert 45°
USB charger C 60W
Custom Module 1
Dimensions 336 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.611
Number of other sockets 2
Angle of twisted central insert 45°
USB charger A/A 15W
Custom Module 1
Dimensions 294 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.974
Number of other sockets 2
Angle of twisted central insert 45°
USB charger A&C 22W
Custom Module
Dimensions 251 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.975
Number of other sockets 2
Angle of twisted central insert 45°
USB charger C 30W
Custom Module
Dimensions 251 x 86 x 88 mm

Without device supply cable | Power input: 0.2 m with GST18 | Incl. mounting bracket

902.976
Number of other sockets 2
Angle of twisted central insert 45°
USB charger C 60W
Custom Module
Dimensions 294 x 86 x 88 mm
Show more

DESK 2 power strips – white, similar to RAL9010

  • Profile: Aluminium, painted white, similar to RAL9010
  • Socket: Plastic, white
  • Tabletop thickness: 10 – 40 mm

Plastic components white, similar to RAL9010 | Without device supply cable | Power input: 0.2m with GST18 | Incl. mounting bracket

Plastic components white, similar to RAL9010 | Without device supply cable | Power input: 0.2m with GST18 | Incl. mounting bracket

Number of other sockets
Angle of twisted central insert
USB charger
Custom Module
Dimensions

Plastic components white, similar to RAL9010 | Without device supply cable | Power input: 0.2m with GST18 | Incl. mounting bracket

902.3230
Number of other sockets 2
Angle of twisted central insert 45°
USB charger A&C 22W
Custom Module
Dimensions 225 x 85 x 100 mm

Plastic components white, similar to RAL9010 | Without device supply cable | Power input: 0.2m with GST18 | Incl. mounting bracket

902.3231
Number of other sockets 2
Angle of twisted central insert 45°
USB charger A&C 22W
Custom Module
Dimensions 293 x 85 x 100 mm

Plastic components white, similar to RAL9010 | Without device supply cable | Power input: 0.2m with GST18 | Incl. mounting bracket

902.3232
Number of other sockets 3
Angle of twisted central insert 45°
USB charger
Custom Module
Dimensions 285 x 85 x 100 mm

Plastic components white, similar to RAL9010 | Without device supply cable | Power input: 0.2m with GST18 | Incl. mounting bracket

902.3233
Number of other sockets 2
Angle of twisted central insert 45°
USB charger A&C 22W
Custom Module 1
Dimensions 293 x 85 x 100 mm
Show more

Downloads


DESK 2 (271.8 kB)

Mounting instructions

DESK 2 (789.6 kB)

Mounting instructions

DESK 2 (784.7 kB)

Mounting instructions
